| Applicable | API 6D or API 6A |
| Standards | Design according to ASME B16.34 or ASME VIII Div. 1 & 2 |
| Pressure Class | ANSI Class 150 lbs. to 4500 lbs. |
| Range | API6A Class 3000 PSI to 20000 PSI |
| Size Range | API 6D – from 1/2″ to 42″ API 6A – from 1.13/16″ to 13.5/8″ |
| Ends Design | Flanged (RF/RTJ) – ASME B16.5 or ASME B16.47 Flanged (6B/6BX) – API 6A Compact (Norsok Standard L-005) Butt-Weld (ASME B16.25) and/or Butt-Weld + Pipe Hubbed according to client Clamp Special client’s requirements |
| Body Design | Single piece |
| Closure Design | Bolted Bonnet or Pressure seal |
| Ball Support | Trunnion (small sizes < 4") – Support Plates |
| Seat Design | Floating Self-Relieving – Floating Double Piston Effect Soft Sealing – Metal to Metal (Tungsten Carbide Coating) |
| Valve Operation | Manual: Lever or Gearbox Actuated: Pneumatic / Hydraulic / Electric / Electro-Hydraulic |
| Available Materials | CS, LTCS, SS, Duplex SS, Super Duplex SS, 6Mo, Inconel, Incoloy, Hastelloy, Monel, Titanium NACE MR0175 according to client request. |
| Additional Features | Double Block and Bleed, Double Isolation Barrier (DIB), Anti Blowout Stem, Antistatic Device |
| Testing and Certification | Testing: Hydrostatic, High Pressure Gas, Pneumatic and Functional API 598 – API 6A PSL3G, API 6A PR2 & Endurance Fire testing: API 6FA, API 607, BS 6755 part 2 Fugitive Emission Test: ISO 15848 – 1 & 2 SIL Certificate up to SIL 3 PED 2014/68/UE Mod.H |
