| Function | Differential, Reducing, Relief |
| Diameters | From ½” up to 2” |
| Connections | Flanged (ANSI or PN) (std), Threaded (F-NPT or GAS/BS) |
| Seat | Single |
| Max Rating | Inlet ANSI 1500 / Outlet ANSI 600 |
| CV | From 0,031 up to 12,8 |
| Body Material | “exotic” materials, carbon steel, stainless steel |
| Trim Material | “exotic” materials, stainless steel (std) |
| Diaphragms | EPDM, FKM, other, polychloroprene, stainless steel |
| Max Inlet Pressure | 280 barg (threaded version up to 1″) |
| Regulated Pressure Range | 0,0012 – 52 barg |
| Min Temperature | -196°C |
| Max Temperature | 300°C |
